S430 HORIZONTAL DIRECTIONAL DRILLING MACHINE

Availability:
Quantity:

Specification

Engine Power KW

179/2200

Size(L*W*H) mm

7500x2240x2260

Max Thrust force

KN

430

Weight T 13

Max Pullback force

KN

430

Diameter of drilling rod

mm φ 83

Max Torque

N.M

18000

Length of drilling rod

m 3

Max Rotary speed

rpm

138

Max diameter of pullback pipe

mm φ 1300(Soil Depended)

Max Moving speed of power head

m/min 42

Max construction length

m 650(Soil Depended)

Max Mud pump flow

L/min 450

Incidence Angle

° 11~20

Max Mud pressure

Mpa 10±0.5

Climbing Angle

° 15


Main Performance Characteristics

1. Close-circuit system is adopted for rotation system; automatic variable system is adopted for push & pull, clamping and walking and it is under load-sensitive control. Advanced hydraulic system increases work efficiency more than 20% , reduces about 50% heat, and saves more than 20% energy compared to traditional system.

2. The machine is equipped with Cummins engine, with high efticiency, power, low fuel consumption, low noise, and strong ability in construction.

3. Wireless-control walking system can ensure the safty when the machine performs walk, transfer and load & unload.

4. The machine is equipped with drill rod φ 83x3000mm, and the machine body occupies a moderate area, meeting the requirement for high efficiency construction in small place.

5. Main hydraulic components are from the international first-class hydraulic components manufacturer, which greatly improve the reliability of the product performance and safety.

6. Electric design is reasonable with low failure rate, which is easy for maintenance.

7.The steel track with rubber plate can not only bear high load,but also satisfy walking on different roads.

8. Rack and pinion system is adopted for push&pull, which is good for high effiency, long life, stable working and maintenance is also convenient.
